Constellation - Gemini (and surrounding region)



Click Images for Larger Version

After photographing Orion, I decided to move onto other constellations since Orion had set by the time I got to the telescope the second night.

I aligned the color channels, added the frames after dark-subtracting, and adjusted the levels and curves to bring out the stars and colors and suppress the sky glow due to a lack of flatfielding. I adjusted it until I got approximate true-color back. Then I duplicated the image, set the top layer mode to Screen, and did a Gaussian Blur. I then adjusted the levels to bring the blur -> glow up and that created the glowing stars.

There are two versions of the final image. One of them is annotated with the bright stars (in smaller font), the deep sky objects that are visible in the image, and the astronomical constellations in large gray font. There are deeper sky objects in the field of view, but they are not visible in this image due to the processing and and moon about a third of the sky away.

Object Constellation - Gemini (And Surrounding Area)
Common Name --
Date, Time, & Moon March 4, 2006; 32% Full Moon
Location SBO Telescope at CU Boulder
Optics 24 mm lens; f/5.6
Camera Canon Digital Rebel 350D XT; ISO 100
Exposure Time 1600 seconds total; 4 400-second exposures stacked
Optical Correction Dark- and Flatframe-Correction
Camera Position Normal Camera Lens
Guiding Passive Clock Drive on Equatorial Mount
Processing Details PhotoShop CS - Aligned and averaged color channels; Levels, Curves, and added star glow
Image Size approx. 53° 10' 31" by 35° 27' 0"
Magnitude Depth Approx. 9th magnitude
Notes This was a wider field than I intended to capture since the stars are not nearly as bright as in Orion, so it was hard to tell what I had vs. hadn't captures. A wider field next time is what I will go for.
